kaydon NF045XP0


Bearing Images
  • kaydon NF045XP0 NF045XP0 Bearing represents a specialized category of thin section bearings. It is distinguished by its unique cross-sectional geometry, which remains constant as the bore diameter increases. NF045XP0 bore dia is 4.5". Its out dia is 6". Its width is
Bearing Parameters
Availability
Brand kaydon bearing brand
Model NF045XP0 Constant Section Bearings
Weight (kg) 2.1 lbs
Technical Data
Part Number NF045XP0
Brand KAYDON
System of Measurement Inch
Bearing Type Ball
For Load Direction Four Point Contact
Construction Single Row
Surface Chromium Plating
Seal Type Open
Thin Section Bearings Type Endura-kote Plated Bearings
Series NF 3/4" x 3/4"
Bore Dia 4.5"
Bore Dia Tolerance -0.0008"– 0"
Outer Dia 6"
Outer Dia Tolerance -0.0008"– 0"
Width 0.75"
Width Tolerance +.000 –.005"
External Diameter On Inner Ring 5.055"
Internal Diameter On Outer Ring 5.445"
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Brass
Dynamic Radial Load 4923 lbf
Dynamic Thrust 7300 lbs
Dynamic Moment 9695 lbs
Static Radial Load 5930 lbf
Static Thrust 14810 lbs
Static Moment 15550 lbs
Moment Load Rating 9 ft-lbs
Lubrication Lubricated
Shaft Mount Type Press Fit
Temperature Range -30°C to 110 °C
ABEC Rating ABEC-1
Radial Clearance 0.0000 – 0.0005"
RoHS Compliant
Weight 2.1 lbs
